CONSTRUCTION:
Asseals 3000 Asbestos emulsion sheet
It is made from synthetic emulsion, asbestos fiber and filling material. Normal used for automobile, agricultural machinery, motorcycle, engineering machinery etc., suitable for lubricating oil under temperature 200℃
Asseals 3000V Vulcanized Asbestos beat sheet
It has smooth face and high density compared with Style 3000
PROPERTIES & APPLICATION:
Gasket materials for explosion engine cylinder gaskets and chemical gaskets
Suitable to sealing lubricating oil at highest temperature 250℃
Item |
Style |
3000 |
3000V |
Density g/cm3 |
0.9~1.1 |
1.2~1.4 |
Tensile strength ≥Mpa |
2.5 |
5 |
Compressibility ≥% |
40±7 |
20±5 |
Recovery ≥% |
20 |
40 |
Stress relaxation ≤% |
30 |
30 |
In 20# aviation oil,
150℃, 30min |
Oil absorption |
≤50% |
≤30% |
Thick. increase |
≤6% |
≤12% |
In water
15~30℃, 5h |
Thick. increase |
≤6% |
≤12% |
Normal color: Grey, Black, White, other color on request
Also available with anti-stick : 3000S, 3000VS
or graphite coating : 3000G, 3000VG
THICKNESS TOLERANCE:
Item |
Tolerance |
In same sheet |
Thickness |
±mm |
mm |
0.5 |
0.05 |
0.06 |
0.6-0.8 |
0.06 |
0.08 |
1-2 |
0.08 |
0.08 |
FORMS OF SUPPLY:
Sheets
Width: 500mm; 1000mm
Length: 500mm; 1000mm; 1200; 1500mm
Thickness: 0.4~2.0mm
Cut gaskets ---G3000, G3000V
Dimensions according to drawings or specifications.
CONSTRUCTION:
Asseals CAF are made from selected asbestos fibre, natural rubber, filling material and dye. A price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this jointing the most economical sheet packing choice in the wide range of industrial fields.
PROPERTIES & APPLICATION:
Item |
Style |
3030 |
3035 |
3040 |
3045 |
Tensile strength≥Mpa |
9 |
12 |
15 |
19 |
Aging
coefficient |
0.9 |
0.9 |
0.9 |
0.9 |
Loss on ignition
≤% |
30 |
30 |
28 |
28 |
Compressibility
≥% |
12±5 |
12±5 |
12±5 |
12±5 |
Recovery
≥% |
40 |
40 |
45 |
45 |
Density g/cm3 |
1.6~2.0 |
Tmax: ℃ |
300 |
350 |
450 |
550 |
Pmax: Mpa |
3.0 |
4.0 |
5.0 |
6.0 |
Resistance
to media |
Water, seawater, steam, diluted acid & alkali, gases, alcohols, salt solutions etc. under temperature and pressure. |
Lower Grade 3015, 3025 on request
Available color: Purple, red, black, grey etc.
Available with tin steel, copper, SS304 etc. wire mesh insertion (30**I)
Also available with anti-stick£¨30**S£©or graphite coating (30**G)
FORMS OF SUPPLY:
Sheets:
4000×1500mm; 2000×1500mm;1500×1500mm;
1500×1000mm;1270×1270mm; 3810×1270mm;
3810×2700mm
Thickness: 0.5~6mm
Cut gaskets
G3015~G3045
Dimensions according to drawings or and standards
CONSTRUCTION:
Asseals CAF3050 is made from selected asbestos fibre, natural rubber, filling material and dye. A price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this jointing the most economical sheet packing choice in the wide range of industrial fields.
Asseals 3050G is CAF 3050 with both graphite coating
Asseals 3050GI is CAF 3050 reinforced by wire mesh with both graphite coating
PROPERTIES & APPLICATION:
Item |
Style |
3050 |
3050G |
3050GI |
Tensile strength≥Mpa |
19 |
19 |
25 |
Aging
coefficient |
0.9 |
0.9 |
0.9 |
Loss on ignition
≤% |
28 |
28 |
28 |
Compressibility
≥% |
12±5 |
12±5 |
12±5 |
Recovery
≥% |
45 |
45 |
45 |
Density g/cm3 |
1.8~2.0 |
1.8~2.0 |
2.0~2.2 |
Tmax: ℃ |
500 |
550 |
550 |
Pmax: Mpa |
12.0 |
12.0 |
20 |
Normal color |
Purple red |
Graphite |
Graphite |
Resistance
to media |
Water, seawater, steam, diluted acid & alkali, gases, alcohols, salt solutions etc. under temperature and pressure. |
Available colour: Purple, Black, grey, etc.
Also available with anti-stick:3050S£¬3050GS£¬3050GIS
FORMS OF SUPPLY:
Sheets:Thickness: 0.4~6mm
2000×1500mm; 1500×4000mm;
1500×1500mm; 1500×1000mm;
1270×1270mm; 3810×1270mm
Cut gaskets:
CAF G3050, G3045G, G3045GI
Dimensions according to drawings or specifications and standards
CONSTRUCTION:
Asseals oil-resisting OCAF, a cost effective oil resistance asbestos-rubber sheets, are made from selected asbestos fibre, natural rubber, filling material and dye.
Used in pipelines and apparatus of petrochemical & oil fields
PROPERTIES & APPLICATION:
Item |
Style |
3115 |
3125 |
3130 |
3140 |
Tensile strength≥Mpa |
9 |
11 |
12.7 |
13 |
Compressibility≥% |
12±5 |
Recovery≥% |
35 |
45 |
50 |
50 |
Density g/cm3 |
1.6~2.0 |
Tmax: ℃ |
150 |
250 |
300 |
400 |
Pmax: Mpa |
1.5 |
2.5 |
3.0 |
4.0 |
At 20# air lub oil,15~30℃ for 30min |
Tensile strength≥Mpa |
8 |
9 |
10.8 |
26 |
Oil absorption≤ % |
23 |
23 |
23 |
9 |
Thickness increase% |
|
20 |
15 |
15 |
At 75# gasoline /3# 15~30℃
for 5h |
Tensile strength≥Mpa |
6 |
7 |
7.9 |
14.7 |
Oil absorption≤ % |
22 |
22 |
22 |
15 |
Thickness increase% |
|
25 |
25 |
20 |
Oil sealing Mpa |
8 |
10 |
15 |
12 |
Resistance to media |
Oils, refrigerators, solvents etc. |
Special grade 3150 on request (500 ℃, 10Mpa)
Available colour: Green, blue, white etc.
Available with tin steel, SS304 etc. wire mesh insertion (Style: 31**I)
Also available with anti-stick (Style:31**S) or graphite coating (Style: 31**G)
FORMS OF SUPPLY:
Sheets:
1500×4000mm, 1500×2000mm
1500×1350mm, 1500×1000mm
1270×3810mm, 1270×1270mm
Thickness: 0.4~6mm
Cut gaskets
G3115~G3040
Dimensions according to drawings or and standards.
CONSTRUCTION:
Asseals Acid-resisting ACAF is made of good asbestos fiber with acid-resisting synthetic rubber compression heating and compression molding it.
APPLICATION:
Mainly used for the equipment in acid, and used as sealing materials of gaskets for the flange of pipeline joints.
PROPERTIES:
Item Style
|
3235 |
3225 |
3220 |
Horizontal Strain MPa≥ |
14 |
11 |
8 |
Weight-increasing |
96.17%( H2SO4) =18mol/L*48h |
≤30% |
≤30% |
≤30% |
36.97%(HCL)=12mol/L*48h |
≤25% |
≤25% |
≤25% |
10% (HNO3)= 1.67mol/L*48h |
≤20% |
≤20% |
≤20% |
Max. Pressure Mpa |
4.0 |
2.5 |
2.0 |
Max. Temperature ℃ |
350 |
250 |
200 |
Strain-decreasing %≤ |
50 |
Aging Coefficient |
0.9 |
Softness |
No Crack |
Density g/cm 2 |
1.8-2.0 |
Burning Loss % |
30 |
Compressibility |
12±5 |
Elasticity≥% |
40 |
FORMS OF SUPPLY:
Sheets:
1500×4000mm, 1500×2000mm
1500×1350mm, 1500×1000mm
1270×3810mm, 1270×1270mm
Thickness: 0.4~6mm
Cut gaskets:
ACAF G3220, G3225, G3235
Dimensions according to drawings or specifications and standards
CONSTRUCTION:
Asseals CAF 3025 are made from selected high quality asbestos fibre, natural rubber, filling material and dye. A price worthy quality of dependable performance, plus adaptability to many sealing requirements makes this jointing the most economical sheet packing choice in the wide range of industrial fields.
PROPERTIES & APPLICATION:
Item |
AIFLON Style 3025 |
Tensile strength≥Mpa |
7 |
Aging
coefficient |
0.9 |
Loss on ignition
≤% |
30 |
Compressibility
≥% |
12±5 |
Recovery
≥% |
40 |
Density g/cm3 |
1.9 |
Tmax: ℃ |
250 |
Pmax: Mpa |
2.5 |
Resistance
to media |
Water, seawater, steam, diluted acid & alkali, gases, alcohols, salt solutions etc. under temperature and pressure. |
Available colour: Black, grey, red, blue etc.
Available with tin steel, copper, SS304 etc. wire mesh insertion, or double tanged metal faces
Also available with anti-stick or graphite coating (3025G)
Other printed (on one face), on request.
FORMS OF SUPPLY:
Sheets:
Width: 1270mm
Length: 1270mm, 3810mm
Thickness: 0.5~5mm
Cut gaskets:
ASSEALS CAF 3025/G
Dimensions according to drawings or specifications and standards |
