| AS MJ5000DJ Metal Jacketed Gasket |
| Item: AS MJ5000DJ |
| Description: Metal jacketed gasket Aiflon Samsung Metal Jacketed gasket(MJG)is made from graphite,ceramic,non-asbestos etc.filler covered with thin metal jacket,such as stainless teel,carbon steel,copper etc., special used in sealing spots of heat exchanger,pressure vessel etc. this gaskets highly resistance against blow-out ,suitable for high assembly stress |
PDF:
|
 |
| Hits: 1197 |
|
| |
|
| Specification: |
5000DJ Double Jacketed plain gasket
5000DC Double Jacketed corrugated gasket
5000H DJG for Heat Exchanger
5000S DJG with special shape
|
Filler material |
Jacket meterial |
Temperature |
Pressure，Mpa |
|
Graphite, Asbestos
Non-asbestos
Ceramic
PTFE |
Carbon steel |
300 |
SPAN>6.4 |
|
Copper |
400 |
SPAN>6.4 |
|
304,316 |
530 |
SPAN>6.4 | |
|
|
